6.2.5 HYBRID mode VLAN configuration
Before the port is configured for VLAN, the VLAN mode of the port should be specified as
the HYBRID mode。In this VLAN mode, the port defaults to the VLAN1 member of untagged,
and the default VLAN of the port is 1。The VLAN configuration command of HYBRID mode is
as follows：
command
describe
CLI mode
switchport hybrid vlan
<vlan-id>
The configuration port is the
untagged member of the
specified VLAN, and the
default VLAN of the port is
the specified VLAN
。
Parameters range from 2 to
4094。
Interface
configuration
mode
no switchport hybrid vlan
The port is cleared from the
default VLAN, no longer the
default VLAN's tagged or
untagged member, and the
default VLAN of the port
returns to 1
。
Interface
configuration
mode
switchport hybrid allowed vlan
all
Configuration ports are all
tagged members except VLAN
(except VLAN1). For the
newly created VLAN, the port
is also the tagged member of
these VLAN
。
Interface
configuration
mode
switchport hybrid allowed vlan
none
Except for VLAN1, the port is
no longer a member of all
other VLAN's tagged or
untagged, and the default
VLAN of the port returns to 1
。
Interface
configuration
mode
switchport hybrid allowed vlan
Configure the port to be the
Interface
