■ Do not try to cut stems or twigs that are larger than

15 mm thick, or those obviously too large to feed into

the cutting blade. Use a non-powered hand saw or

pruning saw to trim large stems.

■

If desired, you can use a string to help cut your hedge

level. Decide how high you want the hedge. Then,

stretch a piece of string along the hedge at this height.

Trim the hedge just above this guide line of string.

See Figure 4. Trim the side of a hedge so that it will be

slightly narrower at the top. See Figure 5. More of the

hedge will be exposed when shaped this way, and it will

be more uniform. If blades do become jammed, stop the

motor, allow the blades to stop and remove the battery

pack before attempting to remove the obstruction.

■

Wear gloves when trimming thorny or prickly growth.

When trimming new growth, use a wide sweeping

action, so that the stems are fed directly into the

cutting blade. Older growth will have thicker stems and

will be trimmed easiest by using a sawing movement.

DANGER

If blade jams on any electrical cord or line,

DO NOT TOUCH THE BLADE! IT CAN BECOME

ELECTRICALLY LIVE AND VERY DANGEROUS.

Continue to hold the hedge trimmer by the insulated

rear handle or lay it down and away from you in a

safe manner. Disconnect the electrical service to the

damaged line or cord before attempting to free the

blade from the line or cord. Failure to heed this warning

will result in serious personal injury or possible death.

WARNING

Clear the area to be cut before each use.

Re-move all objects such as cords, lights, wire, or

string which can become entangled in the cutting blade

and create a risk of serious personal injury.

WARNING

CAUTION

Do not at any time let brake fluids, gasoline,

petroleum based products, penetrating oils,

etc., come in contact with plastic parts. They

contain chemicals that may damage, weaken, or

destroy plastics.

MAINTENANCE AND REPAIR

BLADE MAINTENANCE – HEDGE TRIMMER

WARNING

Battery units do not have to be plugged into an

electrical outlet; therefore, they are always in operating

condition. To prevent serious personal injury, always

remove the battery and take extra precautions and

care when performing maintenance, service or for

changing the cutting blade.

WARNING

To prevent serious personal injury, remove the battery

pack before servicing, cleaning, or removing material

from the unit.

BLADE CARE

Lubricate the cutting blades after each use.

Periodically inspect the blades for damage and wear.

Always use the manufacturer's specified replacement

blades.

TO LUBRICATE BLADE

See figure 6

Remove battery pack from hedge trimmer.

For easier operation and longer blade life, lubricate the

hedge trimmer blade before and after each use. Before

lubricating, remove the battery pack and lay hedge

trimmer on a flat surface. Apply light weight machine

oil along the edge of the top blade. See Figure 8.

Occasionally, you should oil your hedge trimmer during

prolonged use. Before oiling, stop hedge trimmer,

remove battery pack, then oil. You then can resume

trimming. Do not oil while hedge trimmer is running.

Avoid using solvents when cleaning plastic parts. Most

plastics are susceptible to damage from various types

of commercial solvents and may be damaged by their

use. Use a clean cloth to remove dirt, oil,grease, etc.

When servicing use only identical Greenworks Tools

replacement parts. Use of any other parts can create a

hazard or cause product damage.
