SIERRA VIDEO

Overview

SVG MultiViewer

Introduction

The SVG uses a 1RU platform (04-SVG-FRAME) with six slots with 3 input card and 1 output card

options:

Three input module choices:

04-SVG-CVSD: 4 x SD input card (auto-sensing CVBS/SDI)

04-SVG-3GHD: 4 x HD3G input card (auto-sensing HD/SD SDI up to 3G)

04-SVG-HDMI: 4 x HDMI input card (up to 1080p/60Hz)

One output module choice:

04-SVG-OM-HDHDMI: HDMI + HDSDI output card: Output resolution of HDMI signal up to

1920x1080p or 1920x1200p. (Each output card provides one HDMI input and one RJ45 interface

for Ethernet)

The SVG is equipped with either a single output card or dual output cards. The single output SVG can

hold up to five input cards. So it supports up to 21 (20+1) input signals (the +1 is the HDMI input on

the output module). Input sources can be routed (duplicated) to display on any of that specific

module's four channels on the single display.

The SVG can also be equipped with two output cards, and up to four input cards. So it supports up to

18 (16+2) input signals (the +2 are each HDMI input on the two output modules). Inputs can be

assigned to display on any, or both, outputs. Any channel can be directly and simply moved from one

screen to another screen in real-time. Input sources can be routed (duplicated) to display on any of

that specific module's four channels on either or both of the SVG's output displays. The only

restriction is that the local HDMI inputs on each output module can only be displayed on the same

output as the card on which they reside.

The SVG is a MultiViewer display system with rich features of high-quality, multi-format inputs,

flexible and customizable functions, audio metering, waveform display, real time monitoring and

dynamic UMD & Tally from routers with Alarms and audio monitoring. It can be widely used in studio,

broadcasting, general control centers, and post-production editing facilities. This makes it ideal for

many applications where video/audio monitoring and display are required!
