![Kramer SierraView™ SVG Multi Viewer [83/85] Specifications](/views2/1153911/page83/bg53.png)
SVG MULTIVIEWER
73
Specifications
SVG-CVSD SDI/CVBS AUTO-SENSING INPUT MODULE
Impedence
75 Ohms
Input formats
Composite: PAL/NTSC
SD-SDI: SMPTE 259M-C (525/625 lines)
Audio input
4 balanced analog mono inputs (3-pin 600 Ohms Phoenix) via 15
pin mini-adapter.
Maximum input level: +24dBu (0dbFS)
Sampling: 48KHz
Frequency response: <+/-0.04dB @ 20Hz to 20KHz
Tally Input
4 per input module (3-pin Phoenix) via 15 pin mini-adapter
SVG-3GHD HD-SDI AUTO-SENSING INPUT MODULE
Impedence
75 Ohms
Input formats
SD-SDI: SMPTE 259M-C (525/625 lines)
HD-SDI: SMPTE 292M
3G HD-SDI: SMPTE 424M
Input resolutions
720p 23.98/24/25/29.97/30/50/59.94/60
1080i 50/59.94/60
1080p 23.98/24/25/29.97/30/50/59.94/60
Audio input
4 SDI inputs with embedded audio; four channels of Group 1
displayed.
Maximum input level: +24dBu (0dbFS)
Sampling: 48KHz
Frequency response: <+/-0.04dB @ 20Hz to 20KHz
Tally Input
4 per input module (3-pin Phoenix) via 15 pin mini-adapter
SVG-HDMI HDMI INPUT MODULE
Impedence
75 Ohms
Input resolutions
720p 23.98/24/25/29.97/30/50/59.94/60
1080i 50/59.94/60
1080p 23.98/24/25/29.97/30/50/59.94/60
Audio input
4 HDMI inputs with embedded audio; four channels of Group 1
