Kramer SierraView™ SVG Multi Viewer [84/85] General

SIERRA VIDEO

displayed.

SVG-OM-HDHDMI HD-SDI/HDMI VIDEO OUTPUT MODULE

(With single HDMI input)

Output formats

One HDMI V1.3 output, HDCP supported

Output resolutions

HDMI Output: 1024x768p, 1280x720p, 1280x768p,

1280x1024p, 1360x768p, 1400x1050p, 1600x1200p,

1680x1050p, 1920x1080p, 1920x1080i, 1920x1200p

HD-SDI Output: 576i 50(PAL only), 480i 59.94 (NTSC only),

720p, 1080i, 1080p

Input formats

One HDMI V1.3 input

Input resolutions

720p 23.98/24/25/29.97/30/50/59.94/60

1080i 50/59.94/60

1080p 23.98/24/25/29.97/30/50/59.94/60

Network interface

RJ45 (100/1000)

GENERAL

Size

17.5” W x 19” D x 1.75” (1RU) H

445mm W x 483mm D x 44mm (1RU) H

Weight

10lbs

4.54 KG

Power Requirements

100-250VAC, 120W
