ZyWALL USG Support Notes
156
All contents copyright (c) 2010 ZyXEL Communications Corporation.
I. Application Patrol FAQ
I01. What is Application Patrol?
Application Patrol is to inspect and determine the application type accurately by
looking at the application payload, OSI layer 7, regardless of the port numbers.
.
I02. What applications can the Application Patrol function
inspect?
AppPatrol on ZyWALL USG supports four categories of application protocols at the
time of writing.
1. General protocols -- HTTP, FTP, SMTP, POP3 and IRC.
2. IM category -- MSN, Yahoo Messenger, AOL-ICQ, QQ
3. P2P category -- BT, eDonkey, Fasttrack, Gnutella, Napster, H.323, SIP, Soulseek
4. Streaming Protocols -- RTSP (Real Time Streaming Protocol)
Note: The applications support is not configurable (add or remove).
Protocol
Type
Protocol
Application Type/Version
Action Block
Block of Access
BWM over the Application
Common
FTP
Filezilla 2.2.18, 2.2.19 (Active)
Protocol detect
Yes
Yes
Common
FTP
Filezilla 2.2.18, 2.2.19 (Passive)
Protocol detect
Yes
Yes
Common
HTTP
IE 6
Protocol detect
Yes
Yes
Common
HTTP
Firefox 2.0, 1.5
Protocol detect
Yes
Yes
Common
IRC
Protocol detect
Yes
Yes
Common
POP3
Outlook Express 6
Protocol detect
Yes
Yes
Common
SMTP
Outlook Express 6
Protocol detect
Yes
Yes
IM
aol-icq
ICQ 5.1
audio
Yes
No
IM
aol-icq
ICQ 5.1
video
Yes
No
IM
aol-icq
ICQ 5.1
file transfer
Yes
No
IM
aol-icq
ICQ 5.1
Login
Yes
No
IM
aol-icq
ICQ 5.1
Message
Yes
No
IM
jabber
Google Talk 1.0
Login
Yes
No
IM
msn
7.5, 8.0
audio
Yes
Yes
IM
msn
7.5, 8.0
file transfer
Yes
Yes
IM
msn
7.5, 8.0
Login
Yes
No
IM
msn
7.5, 8.0
Message
Yes
No
IM
msn
7.5, 8.0
video
Yes
Yes
