ZyWALL USG Support Notes
73
All contents copyright (c) 2010 ZyXEL Communications Corporation.
Go to Users > New > Users. Add user accounts.
In this example, we add new users “judy”, “nancy”, “chris” and “lucy”.
Please note your AD server‟s domain name. In this example the AD domain is
cso.org.
