ZyWALL USG Support Notes
81
All contents copyright (c) 2010 ZyXEL Communications Corporation.
Step3. Go to Configuration > Object > User/Group > User, add user groups
corresponding to the groups in the AD server.
In this example, we add two groups that correspond to the ones on the AD server:
“cso” and “sales”.
The User Name can be different from the group identifier. E.g. the group identifier of
“cso” group is “cso”, but we can specify a different name such as “cso_support”.
The Group Identifier must follow the format as below:
CN=<cso>,CN=Users,DC=<cso>,DC=<org>
<cso> is the group name on the AD server.
Add group “cso”:
