ZyWALL USG Support Notes
50
All contents copyright (c) 2010 ZyXEL Communications Corporation.
1.11.2.2. When Branch is a ZyNOS ZyWALL
On the HQ USG:
Step1. Go to Configuration > Object > Address, add two address objects. One is
ssl_pool (range 10.0.0.1~10.0.0.10), the other is branch office subnet
subnet_branch(192.168.10.0/24)
