ZyWALL USG Support Notes
33
All contents copyright (c) 2010 ZyXEL Communications Corporation.
via the USG‟s global IP address. Enable NAT Loopback can fulfill this application.
1.6.2. Configuration Steps
Step1. Go to Configuration > Network > NAT, click Add button to add one NAT rule.
Step2. In the rule editing window, fill in all the necessary fields. And enable NAT
Loopback.
