Carte mère MS-7576
Fr-20
Cette carte mère vous fournit les boutons suivants (optinnel) pour régler les fonctions
de l’ordinateur. Cette partie vous explique comment changer les fonctions de votre
carte mère par ces boutons.
Bouton d’effacement : CLR_CMOS1
Il y a un CMOS RAM intégré, qui possède un bloc d’alimentation alimenté par une
batterie externe, destiné à conserver les données de configuration du système.
Avec le CMOS RAM, le système peut lancer automatiquement le système d’exploitation
chaque fois qu’il est allumé. Si vous souhaitez effacer la configuration du système,
utilisez ce bouton pour effacer les données. Appuyez sur ce bouton pour effacer les
données.
CLR_CMOS1
Boutons
Important
Veuillez vous assurer d’éteindre le système avant d’effacer les données
CMOS.
Bouton d’alimentation : POWER1
Ce bouton d’alimentation sert à allumer ou éteindre le système. Appuyez sur ce
bouton pour allumer ou éteindre le système. Ce bouton s’alumera après que vous
allumiez le système et la lumière s’éteindra quand vous éteignez le système.
Bouton de réinitialisation : RESET1
Ce bouton de réinitialisation sert à réinitialiser le système. Appuyez sur ce bouton
pour réinitialiser le système. Ce bouton s’allume quand le système dans le statut S0.
RESET1
POWER1
