Carte mère MS-7576
Fr-26
2. De l’arbre de réglages graphiques dans le Catalyst
TM
Control Center, cliquez
CrossFire
TM
.
3. Du liste Graphics Adapter, choisissez la carte graphique qui fonctionne comme
un Display GPU.
4. Choisissez Enable CrossFire
TM
.
5. Cliquez Apply.
Quand le Hybrid CrossFireX
TM
est activé, GPU Accelerated Physics est désactivé
automatiquement pour que toutes les cartes dans la configuration soient affichées à
part celle utilisée par Hybrid CrossFireX.
Pour plus de détails, veuillez vous référer au
http://game.amd.com/us-en/crossfirex_hybrid.aspx
Important
Le changement du mode d’opération de la mémoire graphique intégrée
peut entraîner l’échec du Hybrid CrossFire. Afin d’éviter ce problème,
veuillez suivre les instructions ci-dessous pour régler le système :
1.Désactivez le Hybrid CrossFire dans le Catalyst Control Center.
2.Réinitialisez dans le BIOS.
3.Choisissez l’option dans Advanced BIOS Features -> Chipset Feature
-> On-Chip VGA
4.Conservez les réglages du BIOS et réinitialisez-le.
5.Activez le Hybrid CrossFire dans le Catalyst Control Center.
