MS-7576 Mainboard
En-2
Mainboard Specifications
Processor Support
- Supports AMD
®
Phenom
TM
II X4/ X3 and Athlon X4 /X3/ X2 processors
in the AM3 package.
(For the latest information about CPU, please visit
http://global.msi.com.tw/index.php?func=cpuform2)
HyperTransport
- HyperTransport 3.0 up to 5.2GT/s
Chipset
- North Bridge: AMD
®
790GX / 780G chipset
- South Bridge: AMD
®
SB710 / SB750 chipset
Memory Support
- DDR3 800/1066/1333/1600(OC) SDRAM (16GB Max)
- 4 DDR3 DIMMs (240pin/1.5V)
(For more information on compatible components, please visit
http://global.msi.com.tw/index.php?func=testreport)
Side Port Memory
- DDR3 SDRAM 1Gbit (optional)
LAN
- Supports LAN 10/100/1000 Fast Ethernet by RTL8111DL
IEEE 1394 (optional)
- Chip integrated by VIA VT6315N
- Transfer rate is up to 400Mbps
- Supports up to 2 ports
Audio
- HD Audio ALC888S / ALC889
- Up to 8-channel audio with jack sensing
IDE
- 1 IDE port by SB710 / SB750
- Supports Ultra DMA 66/100/133 mode
- Supports PIO, Bus Master operation mode
SATA
- 5 SATA II ports by SB710 / SB750
- 1 eSATA port by SB710 / SB750
- Supports storage and data transfers at up to 3 Gb/s
RAID
- SATA1~5 supports RAID 0/ 1/ 10 or JBOD mode by SB710
- SATA1~5 supports RAID 0/ 1/ 10 /5 or JBOD mode by SB750
(optional)
