Ru-26
MS-7576 Системная плата
2. Из Graphics Settings tree в Catalyst
TM
Control Center, выберите CrossFire
TM
.
3. Из списка Graphics Adapter, выберите видеокарту, которая будет выводить
изображение.
4. Выберите Enable CrossFire
TM
5. Нажмите Apply.
При включении Hybrid CrossFireX, функция GPU Accelerated Physics
автоматически выключается, а также отключаются все мониторы, кроме того,
который выводит изображение, создаваемое в режиме Hybrid CrossFireX.
За дополнительной информацией посетите сайт http://game.amd.com/us-en/
crossfirex_hybrid.aspx
Внимание
Изменение режима работы с памятью для интегрированного
графического процессора может привести к нарушению работы
Hybrid CrossFire. Для избежания этой ситуации следуйте данным
указаниям для установки настроек:
1. Выключите Hybrid CrossFire в Catalyst Control Center.
2. Перезагрузите систему и войдите в BIOS
3. Выберите опцию в Advanced BIOS Features -> Chipset Feature ->
On-Chip VGA
4. Сохраните конфигурацию BIOS и перезагрузите систему
5. Включите Hybrid CrossFire в Catalyst Control Center.
