The motherboard provides the following button for you to set the computer’s function.

This section will explain how to change your motherboard’s function through the use

of button.

Clear CMOS Button: CLR_CMOS1

There is a CMOS RAM on board that has a power supply from external battery to

keep the system configuration data. With the CMOS RAM, the system can automati-

cally boot OS every time it is turned on. If you want to clear the system configuration,

use the button to clear data. Press the button to clear the data.

CLR_CMOS1

Buttons

Important

Make sure that you power off the system before clearing CMOS data.

Power Button: POWER1

This power button is used to turn-on or turn-off the system. Press the button to turn-

on or turn-off the system. This button will light after you power-on the system, and

the light will turn-off when you power-off the system.

Reset Button: RESET1

This reset button is used to reset the system. Press the button to reset the system.

This button will light when the system is in S0 status.
