Carte mère MS-7576
Fr-4
Guide rapide des composants
DDR3, Fr-8
Panneau arrière
I/O,
Fr-11
PWR1, Fr-10
CPUFAN1,
Fr-15
JPWR1, Fr-10
IDE1, Fr-13
OCSWITCH1,
Fr-21
SYSFAN3,
Fr-15
SATA1~5,
Fr-14
JFP2, Fr-18
JFP1, Fr-18
JTPM1, Fr-17
JCOM1, Fr-17
POWER1,
Fr-20
CLR_CMOS1,
Fr-20
RESET1,
Fr-20
JUSB1~3,
Fr-16
FDD1,
Fr-13
J1394_1,
Fr-14
JSP1,
Fr-19
JCD1,
Fr-18
JAUD1,
Fr-19
PCI,
Fr-27
PCIE,
Fr-22
SYSFAN1/2,
Fr-15
CPU, Fr-5
JCI1, Fr-15
PDF created with pdfFactory trial version www.pdffactory.com
