12 Before you begin

System requirements

Your PC and system software must meet the

following minimum requirements to use this product:

• IBM PC/AT or compatible

– CPU: 80386SX 66MHz and above

– RAM: 16MB or more

• OS: Microsoft Windows 3.1 or Windows 95

• Hard disk space: 40MB or more depending on the

size and number of images you store.

• A color monitor with a video board or video driver

to display 640 × 480 pixels and 256 colors or better.

(A video board with 16,770,000 colors is

recommended.)

• CD-ROM drive

• RS-232C port (serial speed selectable among

9600bps/19200bps/38400bps) or infrared port

Note

Depending on the PC, the

selectable serial speeds

(bps) are limited.
