Sony Cyber-Shot DSC-F1 [49/128] Capturing an image

49Capturing an image

Capturing an image

Closing an album list, image list or images

Click [Close] in the File menu.

Saving the image

You can save the images in album or other file types.

Refer to “Saving the camera images in album” to save

them in album format, or “Saving the camera images

as another file format” to save them in standard file

type including BMP, TIF, and JPEG.
