88
Capturing an image
About the menus
Open Camera's Image Opens and displays the camera images on the monitor.
Save in Album Saves all the images or selected images of the camera to the
album on the hard disk in the album format without opening
them.
Save as File Saves all the images or selected images of the camera to the
desired folder on the hard disk in JPEG or PICT file type
without opening them.
Save to Camera Transfers the images on the hard disk to the camera.
Undo Undoes the most recent zooming or rotation command.
Copy Copies the selected image or comment to the clipboard.
Paste Pastes the comment of the clipboard. (You cannot use this command if
nothing is in the clipboard. )
Select All Selects all the images in the image list window.
Select None Cancels the selection in the album list or image list window.
Camera menu
Edit menu
