Sony Cyber-Shot DSC-F1 [52/128] Opening an image file directly

Capturing an image

To select the file type: Click the desired file type in

the [List Files of Type] drop-down list

box.

To select the file name: Click the desired file name

in the [File Name] list box or input the

file name directly in the text box.

3 Click [OK].

The image is saved in the selected destination

folder in the file format.

Saving in JPEG file type

When you select [JPEG] file type and click [OK],

the dialog box to define the image quality

(compression ratio) appears. You can select the

image quality within the range from 1 to 100.

Opening an image file directly

Usually, the larger number you select, the lower

compression ratio with the better image quality

you get. The file size, however, becomes larger.
