123
Sony Digital Still Camera Plug-in
Using the Plug-in
continued
Using the Plug-in
You can transfer Digital Still Camera images directly
to an applications which support the Adobe
PhotoShop Plug-in.
Before you start
• Make sure you have done the necessary
preparations as described in pages 82 through 85.
• Set the application memory as large as possible.
(The minimum Memory Requirements: the
Suggested size plus 3000KB to the Preferred size)
1 Start up an application.
2 Select [Acquire] and then [Sony Digital Still
Camera] in the [File] menu. (Menu names differ
depending on the application.)
After your Macintosh accesses the Digital Still
Camera, the image list window appears.
Transferring camera images to your
application
Using the Plug-in
Tool bar
Date or title display
