26
Capturing an image
About the menus
Display menu
Tool Bar Displays (with a check mark) or hide (without a check mark) the tool
bar.
Status Bar Displays (with a check mark) or hide (without a check mark) the
status bar.
Image menu (When an image is displayed)
Information Displays the information about the opened image or selected
image in the image list.
Rotate Left Rotates the image 90 degrees counterclockwise.
Rotate Right
Rotates the image 90 degrees clockwise.
Flip Rotates the image 180 degrees.
Zoom In Enlarges the displayed image size.
Zoom Out Reduces the displayed image size.
Show Edit Frame Displays the frame for trimming a part of the image.
Best Fit 640 × 480
Adjusts the size of the image to fit into 640 × 480 pixels. The image
is enlarged or reduced without changing its aspect ratio.
