89Capturing an image
Capturing an image
Display menu
Zoom In Enlarges the image display size.
Zoom Out Reduces the image display size.
Image menu
Display Frame 640 × 480 Displays the frame for trimming an image in
landscape.
Display Frame 480 × 640 Displays the frame for trimming an image in portrait.
Rotate Clockwise 90 degrees Rotates the image 90 degrees clockwise.
Rotate Counter-Clockwise 90 degrees Rotates the image 90 degrees counterclockwise.
Rotate 180 degrees Rotates the image 180 degrees.
Window menu
Go to First Page Displays the first page of the image list window.
Go to Previous Page Displays one page before the current page of the
image list window.
Go to Next Page Displays one page after the current page of the image
list window.
Go to Last Page Displays the last page of the image list window.
continued
