55Editing an image
Editing an image
Changing the caption
3 Type the caption in the dialog box and click [OK].
The caption is changed.
You can change the comment of albums or images.
The procedure below describes how to change the
image comment. (You can change the album
comment in the same way.)
1 Display the image list of a camera or the hard disk.
See “Opening the camera images” (page 31) or
“Opening an album of the hard disk” (page 47) for
details.
2 Click the caption box underneath the image
thumbnail whose caption you want to change.
The [Image Caption] dialog box appears.
Tips
• You can input up to 14
characters for a caption.
• You can also input a
caption in the Image
Information dialog box.
To display the dialog
box, select
[Information] in the
Image menu or click
on the tool bar.
When the date is
displayed
Select [Show Caption] in
the Option menu. The
date display is replaced
with the caption display.
Caption
dialog box
Caption
box
Inputted
caption
