Sony Cyber-Shot DSC-F1 [82/128] Step 1 installing the software

Setting up

Step 1: Installing the software

Setting up

“Sony Digital Still Camera Album Utility” icon

To transfer Digital Still Camera images onto your PC,

install the “Sony Digital Still Camera Album Utility, ”

or/and “Sony Digital Still Camera Plug-in” onto your

hard disk.

1 Start up your Macintosh.

2 Insert the CD-ROM supplied into the CD-ROM

drive.

3 Open your language folder.

Double-click your language folder* among

English, French, and German.

4 Install the “Sony Digital Still Camera Album

Utility.”

Drag the “Sony Digital Still Camera Album

Utility” icon

onto your hard disk.

*Language install option

You can select the menu

and dialog language

among English, French or

German.
