25Capturing an image
Capturing an image
Copy Copies the selected image to the clipboard.
Paste Pastes an image of the clipboard. (You cannot use this command
if no image is in the clipboard. )
Delete Deletes the selected albums or images of an album.
Select All Selects all the albums in the album list or all the images in the
image list.
Select None Cancels the selection in the album list or image list.
Camera menu
Open Camera Opens and displays the camera image list or the image on the
monitor.
Copy To Album Saves all the images or selected images of the camera to the
album on the hard disk in the album format without opening
them.
Export Camera Images Saves all the images or selected images of the camera to the
desired folder on the hard disk in the BMP, TIFF or JPEG file
type without opening them.
Copy to Camera Transfers the images from the hard disk to the camera.
Edit menu
continued
