Sony Cyber-Shot DSC-F1 [28/128] About the menus

Capturing an image

Window menu

Cascade Displays windows like cascades.

Tile Displays windows like tiles.

Help menu

Help Calls up the online Help window.

Search for Help on Searches for Help on the keywords and topics you enter.

About Album Utility Displays the version number of this program.

Keyboard shortcuts

The descriptions including “Ctrl + C,” “Shift + F5” and “Alt + F4” next to the file

menu stand for keyboard shortcuts. ("+” means pressing the two buttons at the

same time and F means a function key.)

About the menus
