Using the TWAIN data source

4 Click .

The image list appears immediately.

5 Click the images which you want to transfer to the

application, then click

The selected images are transferred to the

application and the application window appears

again.

To transfer another image

Repeat steps 3 through 5 or step 5.

Transfer button

Transferring a camera image to an application which supports

the TWAIN protocol

Note

Depending on the

application, the window

closes after the images

are transferred. If this

occurs, repeat steps 3

through 5.
