23Capturing an image
Capturing an image
Starting “Sony Digital
Still Camera Album
Utility”
Using Windows 95
1 Start up Windows 95 on your PC.
2 Click the [Start] button on the taskbar.
3 Point to [Programs] and to [Sony], and then click
[Sony Digital Still Camera Album Utility].
The “Sony Digital Still Camera Album Utility”
starts up.
The main window appears.
Quitting the “Sony Digital Still Camera Album
Utility”
Select [Exit] in the File menu.
Using Windows 3.1
1 Start Windows 3.1 and run the Program Manager
and double-click “Sony” group.
2 Double-click “Sony Digital Still Camera Album
Utility” icon and select [Open] in the Icon menu.
Quitting the “Sony Digital Still Camera Album
Utility”
Select [Exit] in the File menu.
Sony Digital Still Camera Album Utility
Capturing an image
