122
Editing an image
Edit frame
Transferring a small image
When the option “Fit in size on saving small image” is
checked in the Preferences window, a small image will
be enlarged to 640 × 480 pixels and transferred to the
camera. When the option is not checked, a small
image will be transferred as it is.
Note
For the image quality,
refer to the instruction
manual of the Digital Still
Camera DSC-F1.
Transferring an image to the camera
You can transfer a PICT, JPEG or an album-type
(CAMS) image file to the camera.
1 Display the full-sized image to be transfer to the
camera.
2 Select [Save to Camera] in the Camera menu.
The window defining the image quality (FINE,
STANDARD, and SNAPSHOT) appears.
3 Select the image quality and click [OK].
The image is compressed in the selected image
quality and transferred to the camera.
Transferring a large image
Since the image being stored in the camera is limited
to 640 × 480 pixels, a larger image is reduced
automatically and transferred to the camera. To cut
out part of the image without reducing, select [Display
Frame 640 × 480] (in landscape) or [Display Frame
480 × 640] (in portrait) in the Image menu. Move the
edit frame to crop the area to be transferred and the
follow the steps 2 and 3.
