Sony Cyber-Shot DSC-F1 [34/128] Opening the image directly

Capturing an image

Opening the image directly

1 Select [Open Camera] in the Camera menu or click

on the tool bar.

The following dialog box appears.

Opening the camera images

In the initial status, the image number currently

displayed on the camera.

2 Click [Open Single Image] and input the image

number which you want to open in the [Open

image number] box.

Use the numeric keys to specify the image number

or click up arrow to increase or down arrow to

decrease the number.

3 Click [Open].

The selected images are displayed in full size.
