Sony Cyber-Shot DSC-F1 [53/128] Capturing an image from twain device

53Capturing an image

Capturing an image

You can capture an image from a device that supports

TWAIN protocol.

1 Select [Select Source] in the File menu.

The [Select Source] dialog box appears.

2 Select the desired device and click [Select].

3 Select [Acquire] in the File menu.

4 Follow the users' manual of the TWAIN device to

acquire an image.

Capturing an image from TWAIN

device

What is TWAIN?

TWAIN is the standards

software protocol for

communication between

an application software

and a picture-capturing

device such as a scanner.
