24
Capturing an image
About the menus
The “Sony Digital Still Camera Album Utility”
consists of the following menus. For frequently used
menu items, you can use the tool bar buttons (page
29).
File menu
Open Folder Opens an album folder that is stored in the hard disk or MO
disk and displays images of the album.
Open Selected Album/Image
Opens and displays the selected album(s) or image(s) at a
time.
Open File Opens and displays an image file from the hard disk or MO
disk. The available file types are BMP, TIFF, JPEG and PMP
(Album).
Close Closes the currently active window.
Save Saves the image rotated in the album.
Save As Saves the currently selected image with another file name
onto the selected folder. The available file types are BMP,
TIFF, and JPEG.
Save To Album Saves the image(s) selected in the image list or a BMP, TIFF,
or JPEG file onto the album in the hard disk.
Export Images Saves the-image(s) selected in the image list onto the desired
folder. The available file types are BMP, TIFF, and JPEG.
Acquire Acquires an image file from the TWAIN source.
Select Source Selects a TWAIN source such as a digital scanner.
Print Setup Selects the model name of the printer, paper, and other
settings. (The printer driver needs to be installed prior to
printing. )
Print Displays the dialog box to print an album list, image list, and
image.
Exit Exits “Sony Digital Still Camera Album Utility.”
