Sony Cyber-Shot DSC-F1 [87/128] About the menus
![Sony Cyber-Shot DSC-F1 [87/128] About the menus](/views2/1043036/page87/bg57.png)
87Capturing an image
Capturing an image
Open Album Opens an album that is stored in the hard disk or MO disk and
displays images of the album.
Open Selected Image Opens and displays the selected image(s) in the image list
window at a time.
Open Image File Opens and displays an image file from the hard disk or MO
disk. The available file types are PICT, JPEG and Album
(CAMS).
Close Closes the currently active window.
Save File Saves the image rotation in the album.
Save As Saves the currently selected image with another file name as a
PICT or JPEG file onto the selected folder.
Save in Album Saves the image(s) selected in the image list onto the album in
the hard disk.
Save as File Saves the currently selected image in the image list as a PICT or
JPEG file onto the desired folder.
Print Setup Selects the model name of the printer, paper, and other settings.
(The printer driver needs to be installed prior to printing. )
Print Displays the dialog box to print an image.
Quit Exits “Sony Digital Still Camera Album Utility.”
continued
About the menus
“Sony Digital Still Camera Album Utility” consists of
the following menus. You can also use the tool bar
icons to proceed with part of the menu operations
(page 91).
File menu
