Biostar T-Series TForce4 SE / TForce4 U SE
User’s Manual
14
Digital Audio-out Connector: JSPDIF_OUT
This connector allows users to connect the PCI bracket SPDIF
output header.
Pin
Assignment
1 +5V
2 SPDIF OUT
13
3 Gro und
