C. DDR Installation Notice:
For AMD K8 939 CPU launched before Rev. E, please follow the
table below to install DDR memory module, or the system may not
boot up or may not function properly. (Please refer to Table 1 for
CPU Revision)
“SS” represents Single Side DDR memory module
“DS” represents Double Side DDR memory module
Star sign “*” represents leave the DIMM socket empty
DIMM1 SS/DS
*
SS/DS SS/DS
DIMM2
* * *
SS/DS
DIMM3
*
SS/DS SS/DS SS/DS
DIMM4
* * *
SS/DS
D. Know your CPU Version
AMD Athlon 64 Processor Ordering Part Number Example
ADA 3200 A E P 5 AP
Table 1: AMD Athlon
64 Processor Part Definition
Part Definition Revision Part Definition Revision
AP Rev C0 BI Rev D0
AR Rev CG BN Rev E4
AS Rev CG BP Rev E3
AW Rev CG BO Rev E3
AX Rev CG BY Rev E6
AZ Rev CG BW Rev E6
D. Dual Channel Memory installation
To trigger the Dual Channel function of the motherboard, the
memory module must meet the following requirements:
Install memory module of the same density in pairs, shown in the
following table.
Duual Channel Status DIMM1 DIMM2 DIMM3 DIMM4
Enabled O X O X
Enabled X O X O
Enabled O O O O
(O means memory installed, X means memory not installed.)
The DRAM bus width of the memory module must be the same
(x8 or x16)
Part Definition: AP = Re v C0
(
see Table 1
)
