Biostar T-Series TForce4 SE / TForce4 U SE
User’s Manual
50
Technologie de NVIDIA RAID
Stripping de disque RAID 0 pour des performances système et
applications optimales.
Prise en charge mirroring RAID 1 pour tolérance d'erreurs,
prise en charge pour le4s normes contrôleurs de disque SATA et
ATA-133.
Disques RAID 0+1 en miroir ou en striping pour des performances
plus élevées et une plus grande résistance aux pannes.
(Seulement pour nForce4 Ultra)
RAID 5 offrant une protection intelligente des données et un accès
optimal aux données. (Seulement pour TForce U SE)
Emplacements et connecteurs sur carte internes
1 connecteur pour le lecteur de disquette
1 emplacement PCI-Express x16.
2 emplacements PCI-Express x1.
1 connecteur d'entrée CD-ROM audio-in
1 connecteur de sortie SPDIF-Out
2 connecteurs IDE Ultra DMA 133/100/66/33
4 emplacements PCI
4 ports série ATA
3 connecteurs USB prennent en charge 6 ports USB 2.0 sur le
panneau avant
1 connecteur sur le panneau avant prend en charge les fonctions
du panneau avant
Connecteurs E/S panneau arrière
‘1 port imprimeur
1 prise LAN RJ-45
1 port souris PS/2
1 port clavier PS/2
1 port série (COM2 en option)
4 ports USB 2.0
3 ports audio prenant en charge les équipements de sortie audio 6
voies.
