Biostar T-Series TForce4 SE / TForce4 U SE
User’s Manual
4
CHAPTER 2: HARDWARE INSTALLATION
2.1 INSTALLING CENTRAL PRIOCESSING UNIT (CPU)
A. Central Processing Unit (CPU)
Step 1:
Remove the socket protection cap
.
Step 2: Pull the lever toward direction A from the socket and then raise
the lever up to a 90-degree angle
A
90
