Biostar T-Series TForce4 SE / TForce4 U SE
User’s Manual
64
10/100 LAN PHY
PHY: Realtek 8201CL, ACPI, PCI 電源管理をサポート。
NVIDIA RAID テクノロジ
RAID 0 ディスクストライピングで最高のシステムおよびアプリケ
ーション
パフォーマンスを実現。
RAID 1 ディスクミラーリングがフォールトトレランスをサポー
ト,
SATA と ATA-133 ディスクコントローラ標準を共にサポート。
フォールト トレランスのある最高性能を実現するための RAID
0+1 ディスク ストライピングおよびミラーリング機能。
スマートなデータ保護および最適なデータ アクセスを提供する
RAID 5。(TForce4 U SE のみ)
内部オンボードスロットとコネクタ
1 つのフロッピーコネクタ。
PCI-Express x16 スロット(x1)。
2 PCI-Express x1 スロット(x2)。
CD-ROM オーディオインコネクタ(x1)
S/PDIF アウ(x1) コネクタ
Ultra DMA 133/100/66/33 IDE コネクタ(x2)
PCI スロット(x4)
シリアル ATA ポート(x4)
3つのUSB ヘッダがフロントパネルの 6 つの USB 2.0 ポートをサ
ポート。
1 つのフロントパネルヘッダがフロントパネル機能をサポート。
背面パネル I/O コネクタ
プリンター ポート (x1)
RJ-45 LAN ジャック(x1)
PS/2 マウスポート(x1)
PS/2 キーボードポート(x1)
シリアルポート(x1) (COM2 オプション)
USB 2.0 ポート(x4)
3つのオーディオポートが 6 つのチャンネルオーディオアウト機
能をサポト。
01/20, 2006
