Biostar T-Series TForce4 SE / TForce4 U SE
User’s Manual
54
Tecnología NVIDIA RAID
Intercalación de disco RAID 0 disk para conseguir el mejor
rendimiento del sistema y de las aplicaciones.
Admite simetría de disco RAID 1 para tolerancia de errores,
compatible con las normas de controlador de discos SATA y
ATA-133.
Doble escritura y grabación en disco RAID 0+1 para obtener un
mayor rendimiento con tolerancia a fallos.
RAID 5, que ofrece una protección inteligente de datos y un
óptimo acceso a datos. (solamente para nForce4 Ultra)
Conectores y ranuras integrados e internos
1 conector de disco extraíble.
1 ranura 16X PCI-Express.
2 ranuras PCI-Express 1X.
1 conector de entrada de audio en CD-ROM
1 conector de salida SPDIF
2 conectores Ultra DMA 133/100/66/33 IDE
4 ranuras PCI
4 puertos Serial ATA.
3 cabezales USB soportan 6 puertos USB 2.0 en el panel frontal.
1 cabezal del panel frontal soporta funciones de panel frontal.
Conectores de E/S del panel posterior
1 puerto impresora
1 conector de red LAN RJ-45
1 puerto para ratón PS/2
1 puerto para teclado PS/2
1 puerto serie (COM2 opcional)
4 puertos USB 2.0
3 puertos de audio que admiten 6 conexiones de salida de audio
de 8 canales.
