Biostar T-Series TForce4 SE / TForce4 U SE
User’s Manual
58
Technologii NVIDIA RAID
RAID 0 striping dysku (paskowanie danych) w celu uzyskania
najwyższej
wydajności systemu i aplikacji.
Obsługa RAID 1 mirroring dysku (lustrzane odbicie) dla
zapewnienia tolerancji
błędów, obsługa standardów kontrolera dysków SATA oraz
ATA-133.
RAID 0+1 z paskowaniem danych i mirroringiem celu zapewnienia
najwyższej
wydajności z tolerancją błędu.
RAID 5 oferuje inteligentne zabezpieczenie danych i optymalny
dostęp do
danych. (wyłącznie dla Tforce4 U SE)
Wewnętrzne, wbudowane gniazda oraz złącza
Jedno napędu złącze dyskietek elastycznych.
1 gniazdo PCI-Express x16.
2 gniazda PCI-Express x1.
1 złącze wyjścia SPDIF
1 wejścia audio CD-ROM
2 złącza Ultra DMA 133/100/66/33 IDE
4 gniazda PCI
4 porty Serial ATA.
3 złącza główkowe USB obsługujące 6 portów USB 2.0 na panelu
przednim.
Jedno złącze główkowe panela przedniego, obsługujące
urządzenia panela przedniego.
Złącza I/O na panelu tylnym
1 port drukarki
1 gniazdo LAN RJ-45
1 port myszy PS/2
1 port klawiatury PS/2
1 port szeregowy (COM2 opcjonalny)
4 porty USB 2.0
3 portów audio obsługujące 6 kanałów wyjścia audio.
