Biostar T-Series TForce4 SE / TForce4 U SE
User’s Manual
18
CHAPTER 3: NVIDIA RAID FUNCTIONS
3.1 OPERATION SYSTEM
Supports Windows XP Home/Professional Edition, and
Windows 2000 Professional.
3.2 RAID ARRAYS
NVRAID supports the following types of RAID arrays:
RAID 0: RAID 0 defines a disk striping scheme that improves
disk read and write times for many applications.
RAID 1: RAID 1 defines techniques for mirroring data.
RAID 0+1: RAID 0+1 combines the techniques used in RAID 0
and RAID 1.
RAID 5: RAID 5 provides fault tolerance and better utilization of
disk capacity.
Spanning (JBOD): JBOD provides a method for combining
drives of different sizes in to one large disk.
