Biostar T-Series TForce4 SE / TForce4 U SE
User’s Manual
3
1.2 LAY OUT AND COMPONENTS
JKBMS1
JUSBLAN1
JCOM1
JCOM2
(optional)
JPRNT1
JUSB1
JAUDIO2
JAUDIO1
JKBMSV1
JUSBV1
JAT XP WR2
JAT XP WR1
PEX16
PEX1_1
PEX1_2
PC I1
PCI3
PCI2
PCI4
JSPDIF_OUT
JCDIN1
BIOS
DIM M1
DIM M2
JSATA1
JSATA2
JSATA3
JSATA4
JUSB3 JUSB4JUSB2
IDE2
IDE1
FDD1
JCFAN 1
JSFAN1
BAT1
JN BFAN1
JCMOS1
JUSBV2
JCI1
JPANEL1
Codec
Super I/O
DIM M3
DIM M4
Socket 939
LAN
nForce4
or
nForce4 Ultra
Note: ■ represents the 1st pin.
