TForce4 SE / TForce4 U SE
31
CPU FAN Control by
The Choice “smart” can make your CPU FAN to reduce noise.
The Choices: SMART(default), Always On.
CPU Fan Off<℃>
If the CPU Temperature is lower than the set value, FAN will turn off.
The Choices: 16 (default).
Min= 0, Max= 127, you can key in a DEC number.
CPU Fan Start<℃
℃℃
℃>
CPU fan starts to work under smart fan function when arrive this set value.
The Choices: 32 (default).
Min= 0, Max= 127, you can key in a DEC number.
CPU Fan Full speed <℃>
When CPU temperature is arriving the set value, the CPU fan will work under Full Speed.
The Choices: 52 (default).
Min= 0, Max= 127, you can key in a DEC number.
Start PWM Value
The Choices: 32 (default).
Min= 0, Max= 127, you can key in a DEC number.
Slope PWM
The Choices: 1 PWM Value/℃
℃℃
℃ (default), 2 PWM Value/℃, 4 PWM Value/℃, 8 PWM
Value/℃,16 PWM Value/℃,32 PWM Value/℃, 64PWM Value/℃.
Show H/W Monitor in POST
If your computer contains a monitoring system, it will show PC health status during POST
stage. The item offers several delay time for you to choose.
The Choices: Disabled, Enabled (default).
CPU Vcore，
，，
，+3.3V，
，，
，+5.0V/，
，，
，+12.0V，
，，
，5V<SB>，
，，
，Voltage Battery
Detect the system’s voltage status automatically.
CPU Temp
This field displays the current temperature of the CPU.
