Biostar T-Series TForce4 SE / TForce4 U SE
User’s Manual
55
PORTUGUESE
CPU
Suporta o socket 939.
Suporta processadores AMD Athlon 64 FX / Athlon 64 / Athlon 64
X2.
A arquitectura AMD 64 permite uma computação de 32 e 64 bits
em simultâneo.
Suporta um FSB (Front Side Bus) máximo de 1GHz HT.
Suporta a tecnologia HyperTransport™ e AMD Cool’n’Quiet™.
Chipset
NVIDIA nForce4 (TForce4 SE).
NVIDIA nForce4 Ultra (TForce4 U SE).
Suporta o utilitário NVIDIA nTune.
Sistemas operativos suportados:
Suporta o Windows 2000 e o Windows XP.
Nota: Não suporta o Windows 98SE e o Windows ME.
Dimensões
Factor de forma ATX: 29.35 cm (C) x 21.0 cm (L)
Memória do sistema
Suporta DDR de duplo canal.
Suporta módulos DDR 266/333/400.
Capacidade máxima da memória: 4GB, suportando 4 sockets
DIMM.
Serial AT A
TForce4 U SE suporta a especificação Serial ATA 2.0, velocidade
de transferência de dados até3 GB/s.
TForce4 SE suporta a especificação Serial ATA 1.0, velocidade de
transferência de dados até1.5 GB/s.
IDE
Dois conectores na placa para 4 dispositivos.
Suporta o modo PIO 0-4, o modo Block e o modo bus master Ultra
DMA 33/66/100/133.
Especificação Super I/O
Chip: ITE IT8712F.
Iniciativas para controlo do ambiente,
Monitorização do hardware
Controlador da velocidade da ventoinha
Função "Smart Guardian" da ITE
Codec de som AC'97
Chip: ALC665, suporta 6 canais.
10/100 LAN PHY
PHY: Realtek 8201CL, suporta a gestão de energia ACPI, PCI.
