SiBE28-804 Troubleshooting by Remote Controller Display / LED Display
Troubleshooting 155
5.2 Outdoor Malfunctions
Notes: 1. Possibility of open phase in power supply.
Outdoor Unit
Malfunction
Remote
Controller
Display
Location of Malfunction Contents of Malfunction Details of
Malfunction
(Reference
Page)
Other
than PC
Board
PC Board
Outdoor
Unit
Indoor
Unit
Remote
Controller
E1
— — Outdoor unit PC board
malfunction
178
E3
— — — Abnormality of high pressure
(HPS)
179
E4
— — Abnormality of low pressure
(outdoor)
181
E5
— — Compressor motor lock
malfunction
183
E7
Malfunction of outdoor unit fan
motor
185
E9
— — Malfunction of Electronic
expansion valve
188
F3
— — Discharge pipe temperature
malfunction
191
H3
— — Faulty high pressure switch
(HPS)
193
H9
— — Malfunction of outdoor air
temperature sensor system
194
J1
— — Malfunction of pressure sensor 195
J3
— — Malfunction of discharge pipe
temperature sensor system
194
J5
— — Suction pipe thermistor
malfunction
194
J6
— — Malfunction of heat exchanger
temperature sensor system
194
J7
— — Malfunction of subcooling heat
exchanger thermistor (outdoor
unit)
194
J8
— — Malfunction of liquid pipe
thermistor (outdoor unit)
194
L1
— — Outdoor PC board malfunction 197
L4
— — High temperature of radiation fin 199
L5
— — Overcurrent of DC output
(instantaneous)
201
L8
— — Electronic thermal switch
(time lag)
203
L9
— — Stall prevention (time lag) 205
LC
— — Malfunction of transmission
system (between control PC
board and inverter PC board)
207
P1
— — Open phase or voltage
unbalance
209
P4
— — Malfunction of radiator fin
temperature thermistor
210
PJ
— — Error in capacity setting 211
U0
— — — Gas shortage 212
U2
— — Abnormal power supply voltage 214
