Indoor Unit Functional Concept SiBE28-804
60 Functional Description
At compressor
startup
In heating: Hot startup control when performing a startup, or after the defrosting cycle has
been completed, the indoor fan will be controlled as to prevent cold air draft and secure the
starting performance (quick pressure build-up).
Indoor unit fan: OFF
Heating operation is turend on with remote controller.
Indoor unit fan: LL tap
Indoor unit fan: L tap
Indoor unit fan: M tap (Continuing L tap on indoor unit without M tap equipped)
Indoor unit fan: Set fan speed
Condition
A Indoor unit h/e temp > 34°C
B
Indoor unit h/e temp > indoor suction air temp +17°C
(+12°C if outside temperature is < 5°C)
C
Indoor unit h/e temp > indoor suction air temp +22°C
(+20°C if outside temperature is < 5°C)
&
• 1 minute elapsed with LL tap
OR
• Condition A is met.
• Condition B is met.
• 3 minutes elapsed after compressor startup
&
• 1 minute elapsed with L tap
OR
• Condition A is met.
• Condition B is met.
• 5.5 minutes elapsed after compressor startup
&
• 1 minute elapsed with M tap
OR
• Condition A is met.
• Condition C is met.
• 10.5 minutes elapsed after compressor startup
