Daikin RZQ71C7V1B [175/314] A7 swing flap motor malfunction lock
![Daikin RZQ71C7V1B [175/314] A7 swing flap motor malfunction lock](/views2/1769713/page175/bgaf.png)
Troubleshooting by Remote Controller Display / LED Display SiBE28-804
164 Troubleshooting
5.9 “
A7
” Swing Flap Motor Malfunction / Lock
Remote
Controller
Display
A7
LED indications The table below shows the LED indications.
Error generation The error is detected by the limit switch when the motor turns.
When ON/OFF of the microswitch for position detection cannot be reversed eventhough the
swing flap motor is energized for a specified amount of time (about 30 seconds).
Supposed
Causes
The possible causes are:
Failure of swing flap motor
Failure of microswitch
Failure of connector connection
Failure of indoor unit PC board
Operation HAP (green) HBP (green)
Normal
55
Malfunctioning
55
