Troubleshooting by Remote Controller Display / LED Display SiBE28-804
188 Troubleshooting
5.23 “
E9
” Malfunction of Electronic Expansion Valve
Remote
Controller
Display
E9
Applicable
Models
RZQ(S)71~140
Method of
Malfunction
Detection
Method is determined according to the suction pipe superheat degree and electronic expansion
valve opening degree calculated by values of low pressure sensor and suction pipe temperature
thermistor.
Malfunction
Decision
Conditions
When the following conditions are met for 10 minutes
Suction pipe superheat degree < 4°C
Minimum electronic expansion valve opening degree
Connector of electronic expansion valve is missing when the power is on.
Supposed
Causes
Faulty electronic expansion valve
Faulty solenoid valve
Faulty check valve
Disconnection of electronic expansion valve harness
Faulty connection of electronic expansion valve connector
Faulty each thermistor
Faulty mounting
Faulty pressure sensor
Faulty Outdoor control PC board
