Daikin RZQ71C7V1B [54/314] Forced thermostat off
![Daikin RZQ71C7V1B [54/314] Forced thermostat off](/views2/1769713/page54/bg36.png)
SiBE28-804 General Functionality
Functional Description 43
1.8 Forced Thermostat OFF
The unit will perform the forced thermostat off function in following conditions:
Condition 1 (cooling)
Thermostat off due to freeze-up prevention.
Based on the judgment to prevent the indoor heat exchanger from freezing, the thermostat is
forcedly turned OFF.
*1 FHQ Only
Condition 2 (heating)
Thermostat off due to high outdoor temperature.
RZQ71~140C7, RZQS71~140C7
When the outside temperature is > 32°CDB in heating mode, the unit will conduct a
forced thermostat off operation to protect the system.
"Freeze Prevention Function". Refer to P49.
Freeze prevention control
-3ºC
-1ºC
7ºC
Cumulative timer cleared after a continuous 20 minutes
4ºC
Indoor unit
heat exchanger
temperature
(Te)
The thermostat turns OFF after a continuous 1 minute
after 8 minutes from startup (*1)
The thermostat turns OFF after a cumulative 40
minutes
Reset after a continuous 10 minutes and cumulative
timer cleared after a continuous 10 minutes
